PTFE Glass Fiber YS9013AJ

PTFE Glass Fiber YS9013AJ

PTFE Glass Fiber, high glossy and easy release

PTFE Glass Fiber is called as PTFE coated fiberglass fabrics, the basic material is high quality E-Glass, impregnated with high performance PTFE content to produce high glossy, extreme smooth coating.

In order for offering high quality and premier series PTFE Glass Fiber, Youngsun will add special reliable material to modify PTFE property.



PTFE Glass Fiber YS9013AJ

PTFE Glass Fiber YS9013AJ



Choosing high quality E-Glass for PTFE Fiberglass Premier Series



1)  Woven fiberglass will provide excellent mechanical strength for PTFE Glass Fiber, such as tensile strength in fill or warp and tear strength. This will affect the lifetime directly, especially in working environment with high temperature and strong pressure.

2) High quality fiberglass will prevent Teflon Fiberglass from breakage, fall apart, tear and so on.

3) And the surface of the fiberglass will effect the surface of PTFE glass fiber directly, good fiberglass will result in a super smooth surface of PTFE coated fiberglass.



Coating high quality PTFE for PTFE Fiberglass Premier Series



1) High quality Teflon will combine with fiberglass tightly, after laminating many times, the Teflon(PTFE) will still never peel from fiberglass.

2) Imported PTFE like Daikin and Dupont is PFOA free, which can be used to touch food directly, making into belting for food, Non stick oven liner or baking liner, Non stick BBQ mat and so on.

3) High quality PTFE will result in a excellent smooth surface, no defect such as crack, drape and so on. It will also reduce the pin holes on the surface. Easy release in the processing.



Characteristics of PTFE Fiberglass fabric



  Non-stick surface, easy release and low friction

  Working continuous from -73°C – +260°C

  Chemical resistant and environmental resistant

  High tensile strength and dimensional stability

  Reusable and has long lifetime



Technical Data of Teflon coated Glass Fabric



ProductProduct CategoryCoating
PTFE GLASS FABRICPREMIUM SERIESPTFE(TEFLON)



PropertiesMetricImperial
Standard width
Please ask for other widths
1000, 1250, 1500 mm39.5, 49.3, 59.1 inches
Thickness0.13 mm0.0051 inches
Coated weight270 g/m² 7.96 oz/yd²
PTFE content60 %60 %
Tensile strength240 N/cm Warp137 lbs/inches Warp
200 N/cm Fill114 lbs/inches Fill
Temperature resistance-73 to +260 °C-100 to +500 °F



Click here to download Spec of YS9013AJ-ESONE



For samples of PTFE Glass Fiber,  please feel free to contact us.

Note:
Weight Tolerance g/m² = ±%5
All technical data are based on average values. These values are based on test results we believes to be reliable, but they are not to be constured in any manner as warranties expressed.

PTFE coating fiberglass

PTFE coating fiberglass



Click here to access PTFE coated fabric Porous Series
